| Place of Origin: | China |
|---|---|
| Brand Name: | GTGLASS |
| Certification: | CE,ISO |
| Model Number: | GLASS GREENHOUSE |
| Minimum Order Quantity: | 200 square meters |
| Price: | USD 5.9-20.9 m² |
| Packaging Details: | our export packing: 1. steel framework (bundling and packaging); 2.equipment, spare parts (wodden carses, carton packaging); 3. pc sheet, glass, film, and other inderpendent packaging |
| Delivery Time: | 25-30 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000000 m² per month |
| Span: | 9.6m, 10.8m, 12m, Customized | Section: | 4m, Customized |
|---|---|---|---|
| Covering: | Glass | Framework: | Galvanized Steel Structure |
| Ventilation: | Side And Roof Ventilation | Application: | Growing Fruite Vegetable Flower |
| Keyword: | Glass Greenhouse | Optional System: | Irrigation, Shading, Cooling, Hydroponic, Etc |
| Shading System: | Inner Shading System And Outer Shading System | Cooling System: | Cooling Fan And Cooling Pad |
| Height: | 3-6m, Customized | Feature: | Modern Appearance, Stable Structure |
| Highlight: | Large Backyard Glass Greenhouse,Indoor Backyard Glass Greenhouse,Outdoor Backyard Glass Greenhouse |
||
Large Prefabricated Outdoor and Indoor Backyard Glass Greenhouse for flower growing
Venlo-style multi-span glass greenhouse
and beautiful appearance.
the top and around, with strong ventilation capacity, which can prevent heat loss and cold air intrusion.
exhibitions, ecological restaurants, teaching and scientific research, etc.
| Span | 9.6m, 10.8m, 12m , customized |
| Gutter height | 3-6m, customized |
| Greenhouse structure | hot galvanized steel framework |
| Covering | hollow glass, float glass, tempered glass |
| Optional system | ventilation, shading system, cooling system, irrigation, hydroponic, etc |
| Wind load | 0.3kn/m² |
| Snow load | 0.5kn/m² |
| Plants hanging load | 0.15kg/m² |
| Other system | rolling bench system, led light, IOT system |
Framework
1. Suitable for cold weather areas, such as the United States, Canada, Russia and other regions;
2. The greenhouse has a beautiful appearance and a long service life. It is the highest grade product in the greenhouse;
3. The steel materials used in the greenhouse frame structure and connecting parts are all hot-dip galvanized;
Ventilation
Outer shading system
1. The external shading system is fixed on the top of the greenhouse frame, and the shading net is supported by
columns and beams.
2. The framework of the sunshade system is the same as that of the greenhouse, using hot-dip galvanized steel pipes.
3. The outer sunshade net is made of black HDPE material and fixed with black polyester rope.
Inner shading system
1. The internal shading system is fixed under the circular arch of the greenhouse.
2. The sunshade net of the internal sunshade system is made of aluminum foil + polyester yarn, and the white
filter can reflect sunlight and reduce the heat in the greenhouse.
3. The sunshade net has a moisturizing and anti-condensation function, and the woven structure allows sufficient
water vapor to pass through and prevents condensation on the lower part of the sunshade net
About US
Our main products comprise glass multi-span greenhouse, PC-sheet multi-span greenhouse, plastic-film
multi-span greenhouse and solar greenhouse etc.
Moreover, we also have greenhouse materials, they can match all the kinds of greenhouse.
Such as, skeleton system, aluminum-profile system, covering system, shading system, ventilation system,
cooling system, heating system, seedbed system & irrigation system, hydroponics System.
FAQ
1. How long is the delivery time?
According to your greenhouse size and system, the delivery time is usually 15-60 days.
2. Can you supply sample?
Small parts can be supplied, but you should pay the express cost.
3. Can your company supply greenhouse design?
Our company can give greenhouse design according to your land and plan after deposit. And we can give simple
drawing before signing contract.
4. How to install greenhouse ?
Firstly we prepare the material and send the material to your city.
After your customs clearing, we send 2-4 engineers or all workers to guide to install.
If you want to save money, we only send engineers, and you match local workers.
If you think it is hard to build the greenhouse, we also can send engineers and workers to install for you.
5. When installing, what cost should we pay?
Our engineers and workers visas and round-trip tickets, their foods and accommodation, their communication.
